Heatmor CB Series (Coal) and X Series (Wood) Outdoor Furnaces
CB Series Coal Burning Outdoor Furnaces
The CB Series Heatmor outdoor stainless steel furnaces are easy to load, maintain, operate, and are available in a wide selection of colors. Each unit is designed to last and easily integrates with your existing system.
- Lower or eliminate heating bills
- No mess inside your home
- No risk of fire inside your home
- No worry of carbon monoxide poisoning
- Make your home energy independent
Connection Options:
- Home
- Pole Barn/Shop/Garage
- Dairy/Poultry Barns
- Domestic Hot Water
- Radiant Floor Heat
- Commercial Manufacturing
- Pools and Spas
- Greenhouses
- Snow melt
100 CB, 200 CB, 400 CB Features
CB Series Outdoor Coal Furnaces
| Model | 100 CB | 200 CB | 400 CB | 600 CB | 800 CB |
|---|---|---|---|---|---|
| Limited Lifetime Warranty |
YES | YES | YES | YES | YES |
| BTUs | 100,000 | 200,000 | 400,000 | 600,000 | 800,000 |
| Weight | 1.375 | 1,599 | 1,968 | 2,800 | 1,968 |
| Overall Height | 82.5" | 82.5" | 82.5" | 106" | 114" |
| Overall Width | 50" | 50" | 50" | 68" | 90" |
| Overall Length | 65" | 77" | 95" | 102" | 104" |
| Forced Draft (CFM) | 75 | 150 | 2x150 | ||
| Firebox Size (sq ft) | 13 | 20 | 29 | 63 | 135 |
| Heating Area (sq ft) | 3,000 | 5,000 | 10,000 | 18,000 | 25,000 |
| Water Capacity (gal) | 85 | 114 | 155 | 285 | 487 |
| 409 Stainless Steel | YES | YES | YES | YES | YES |
The 200 CBand 400 CBare available as "used oil burner" units at additional cost.
X Series Wood Burning Outdoor Furnaces
Heatmor X series outdoor wood burning furnaces are EPA certified. The X-Series features a new high efficiency grade 409 stainless steel flue design capturing more heat and a redesigned airbox creating a hotter, cleaner burn while using less wood per heat load. The X-series maintains the same proven features as previous Heatmor models. Designed to last!
X Series Features
| Model | 200 X | 350 X |
|---|---|---|
| Limited Lifetime Warranty | YES | YES |
| BTUs | 200,000 | 350,000 |
| Weight | 1,835 | 1,980 |
| Overall Height | 82.5" | 82.5" |
| Overall Width | 50" | 50" |
| Overall Length | 95" | 95" |
| Firebox Size (sq ft) | 13 | 20 |
| Heating Area (sq ft) | 5,000 | 8,000 |
| Water Capacity (gal) | 310 | 270 |
| 409 Stainless Steel | YES | YES |
For the Best Price on a new CB or X series furnaces, in Wisconsin or for more information Contact Greg at
